Orbit Fully Automatic Motorised Satellite TV Dish

SKU: 5573 Price: $2195.00


The Orbit has a 85CM high gain dish to provide coverage for VAST & Foxtel Australia wide. Just press OK, simple.

Utilising the latest in GPS technology to locate your exact location, the Orbit will quickly locate the desired satellite signal.

The SatKing Orbit is built for harsh Australian conditions, it’s rugged, well made with all metal drive gears. Designed in Australia, the unit is perfect for travelling off the beaten track.

The Orbit represents great value for money and is big on features but low on cost.

The SatKing Orbit is backed with a 2 year Australian warranty and fully supported by SatKing, a big Australian-owned company. Need assistance or help whilst on the road? Don’t worry, we have a 1300 helpline to assist you on your travels.


  • 85cm High Gain Dish
  • VAST & Foxtel Compatible
  • Fully Automatic Self Aligning
  • Easy to Use
  • Built in 24CH GPS to Find Satellites Fast
  • Australia-Wide Coverage
  • 2 Year Warranty
  • Dual Output LNB as Standard to Suit Twin Tuner STB’s
  • Suits both Caravans and Motorhomes
  • Automatic LNB Skew
  • Powerful DC Motors with Metal Gearing
  • Weatherproof Construction
  • Made for Harsh Australian Conditions
  • MPEG4 HD Compatible
  • Easy Installation
  • 1300 Number Help Line
  • Designed in Australia
  • Made in Korea

Technical Specifications:

Physical Specifications

  • Dish Dimensions: 86.0 w x 91.0L cm
  • Physical Dimensions: 110.6(L) x 86.0(W) x 18.4(H) cm / 15.1 kg
  • Controller Dimensions: 199.0(w) x 154.0(d) x 31.0(h) mm
  • Product Weight: 13.8kgs
  • Gift Box Weight: 15.1kgs
  • Operating temperature range: -20°C ~ +60°C


  • Polarization: Horizontal/vertical
  • Dual Output Wideband: Dual Output
  • LNB Input Frequency10700
  • LNB output: Dual Output
  • LNB input frequency: 11.75-12.75GHz
  • LNB Output Frequency: 1000 - 2050 MHz

Antenna Adjustment Range

  • Elevation: 0°-145°
  • Azimuth: 390°
  • Skew: -60° ~+60°

Satellite Searching Time

  • Searching time: 80 Seconds (Average)


  • Voltage Range: 10.5-16V
  • Input Voltage: DC 12
  • Consumption: 60 Watts in Search Mode - 4W Standby Mode
